EVOLUTION DIGITAL
EVO6022GP Wi-Fi 6 Dual-Band GPON Gateway
Elevate your connectivity with the Evolution Digital EVO6022GP, a cutting-edge GPON Gateway that brings ultra-fast Wi-Fi 6 and seamless 1 Gbps Ethernet to both home and business. Perfect for high-demand applications like 4K streaming and gaming, this device ensures robust and sophisticated online experiences.
| Specifications | |||
| Interfaces | |||
| WAN/LAN | 1GE Gigabit Ethernet (x1) | LAN | 1GE Gigabit Ethernet (x3) |
| FXS | x1 | USB 3.0 | x1 |
| SC/APC GPON | x1 | TX Wave Length | 1310nm |
| RX Wave Length | 1490nm | Optical Power Value | 0.5~4dBm |
| Maximum Reception Sensitivity | -8dBm | Minimum Reception Sensitivity | -28dBm |
| Software Features | |||
| Plume / OpenSync | OpenSync OS6.4 Certified | DHCP | Server, DHCP Reservation, Static Route |
| WAN Type | Dynamic IP/Static IP/PPPoE/Router | Port Forwarding | Virtual Server, Port Triggering, UPnP, DMZ |
| Access Control | Parental Control, Local Management Control, Host List, Access Schedule, Rule Management |
Firewall Security | DoS, SPI Firewall, IP Address Filter/ MAC Address Filter/Domain Filter, IP and MAC Address Binding |
| VOIP Features | One RJ-11 FXS ports for connecting to analog telephones Call forwarding, Call waiting, Call block, 3-way conference call, etc. | Internet Protocol | IPv4, IPv6 |
| General | |||
| GPON Standards | ITU-T G.984 | Wireless Standards | IEEE 802.11ax/ac/n/a 5 GHz, IEEE 802.11ax/n/b/g 2.4 GHz |
| Data Rates | Upstream 1.25Gbps, Downstream 2.5Gbps | Wireless Security | WEP, WPA / WPA2, WPA-PSK/ WPA2-PSK encryption |
| Operation Frequency | 2.4GHz & 5GHz | Throughput | AX3000 (3.0Gbps), 5 GHz (2x2): 2,402 Mbps (802.11ax), 2.4 GHz (2x2): 574 Mbps (802.11ax) |
| VOIP Standards | SIP (RFC3261), ITU-T G.729/G.722/G.711a/G.711 | Channels | 20/40/80/160MHz support, 2x2 dual-band |
| Physical Specifications | |||
| Size | 9.4 x 5.1 x 2.5 in (240 x 131 x 65 mm) | Weight | 1.3 lbs (.59kg) |
| Operating Temp | 0°C~40°C (32°F~104°F) | Buttons | Power ON/OFF, WPS/Wi-Fi, and Reset |
| Power Supply | DC 12V 1.5A | ||
| Always On | |||
| Cellular Failover | USB EVO LTE Dongle Integrated | ||
