EVOLUTION DIGITAL
EVO1840AP Wi-Fi 6E Tri-Band 2.5G AP Router / Mesh Beacon
EVO1840AP, a cutting-edge Wi-Fi 6E AP router and mesh beacon, empowers service providers with a secure, versatile solution for unparalleled Wi-Fi performance.
Whether as a primary AP or mesh extension, its OpenSync certified technology ensures seamless coverage and enhanced subscriber satisfaction through Plume’s innovative software suite.
| Specifications | |||
| Hardware | |||
| CPU | Quad-core @ 1.6 GHz | ||
| Interfaces | |||
| WAN | 2.5GbE (x1) | LAN | 1GbE (x3) |
| BLE | Bluetooth 5.0 | ||
| Network Features | |||
| Protocols | IPv4, IPv6 | WAN Types | Dynamic IP, Static IP, PPPoE |
| Wi-Fi Encryption | WPA2/3 Personal / Enterprise | WLAN | Guest Network / Multi-SSID |
| QoS | IEEE 802.1p | ||
| Wi-Fi | |||
| Standard | Wi-Fi 6E (802.11a/b/g/n/ac/ax) | Band Config | Tri-Band 2×2 (2.4 GHz) + 4×4 (5GHz) + 2×2 (6GHz) |
| Channel Width | 20, 40, 80, 160 MHz | Peak PHY | 7.8 Gbps |
| Per Band PHY | 0.57 Gbps, 4.8 Gbps, 2.4 Gbps | Peak QAM | 1024K QAM |
| Software Features | |||
| Plume / OpenSync | OpenSync 6.4 Certified | Smart Wi-Fi | Intelligent Mesh, Band/Client Steering |
| CAF Support | Samknows Certified and Streambow Cert In-Process (Via Plume) | Mode | Router or Bridge Mode |
| Physical Specifications | |||
| Size | 6.9 x 5.4 x 2.8 in (175 x 137 X 71 mm) | Weight | 2.5 lbs (1.13 kg) |
| Operating Temp | 0°C~40°C (32°F~104°F) | Power Supply | External, 12V/2A |
| © Evolution Digital, LLC. All Rights Reserved. All values are typical unless noted otherwise. Specifications are subject to change without notification. |
| EvolutionDigital.com |
